VP-175-15A
Voltage Protector
VP-175-15A
VP-175-15A series is wired voltage protector, compact design with high reliability, prevents equipment from the damage of power fluctuations.
Provide with five wires L/N/G for input and output, specially designed for highly sensitive electronics or industrial appliance, provides complete power protection: over-voltage, under-voltage, surges and spikes up to 900Joules.
VP-175-15A (L/N/G)
- Microprocessor control guarantees better performance and high speed response
- Built-in delay reconnection 15 seconds, 30 seconds, 3 minutes
- Provide high / low voltage cut-off protection
- Provide lightning / surge protection
- Designed for industrial equipment
- On/Off switch for power saving
| MODEL | VP-175-15A | ||||||
| INPUT | |||||||
| Nominal Voltage | 110/115/120Vac or 220/230/240Vac | ||||||
| Voltage Range | 90-135Vac or 180-268Vac | ||||||
| Frequency | 50/60Hz (Auto-sensing) | ||||||
| Rated Current | 15A Max. | ||||||
| Plug | L/N/G | ||||||
| OUTPUT | |||||||
| Voltage | Same as input | ||||||
| Frequency | Same as input | ||||||
| Wire | L/N/G | ||||||
| PROTECTION | |||||||
| Power Line Surge Energy Rating | 900 Joules | ||||||
| Delay Reconnection | 15 seconds / 30 seconds / 3 minutes | ||||||
| High/Low Voltage Cut-off | Yes | ||||||
| DISPLAY | |||||||
| LED for Low Voltage | Red | ||||||
| LED for Normal Voltage | Green | ||||||
| LED for High Voltage | Red | ||||||
| LED for Delay Reconnection | LED sparking | ||||||
| ENVIRONMENT | |||||||
| Operating Temperature | 0°C-40°C (32°F-104°F) | ||||||
| Humidity | 0-95% (Non-condensing) | ||||||
| PHYSICAL | |||||||
| Dimension | 44*34*95mm | ||||||
| **Product specifications are subject to change without further notice. | |||||||
