IPT Pro L7 Series 1200VA-3000VA
AVR-Relay Type
IPT Pro L7 Series1200VA-3000VA
IPT Pro 1.2K-3KVA series provides 7-steps voltage regulation to stabilize output voltage for protecting connected devices from damage.
With user-friendly LCD display, users acknowledge AVR status more easily.
To ensure safety of devices connection, IPT Pro 1.2K-3KVA series embedded with thermal switch for over-temperature protection.
With time-delay function, it can avoid connected devices from sudden electrical surges when power is recovered.
IPT Pro Series 1.2KVA-3KVA (7-steps Regulation)
- Comprehensive LCD display shows detailed information of AVR and voltage status
- Provide stable output voltage through 4-steps boost and 3-steps buck stabilizer
- Built-in thermal switch for over-temperature protection
- Provide overload and short circuit protection
- Accept wide input range
- Metal housing
| MODEL | IPT Pro-1200L | IPT Pro-2000L | IPT Pro-3000L | ||||
| CAPACITY | 1200VA/720W | 2000VA/1200W | 3000VA/1800W | ||||
| INPUT | |||||||
| Voltage | 110/115/120Vac or 220/230/240Vac | ||||||
| Voltage Range | 110/115/120Vac: 70-147Vac ; 220/230/240Vac: 140-295Vac | ||||||
| Frequency | 50/60Hz | ||||||
| OUTPUT | |||||||
| Steps of Regulation | 7-steps (4-steps Boost & 3-steps Buck) | ||||||
| Voltage Range | +/-5% | ||||||
| Output Receptacles | Nema5-15R: 4pcs AVR regulated plus surge protected | ||||||
| IEC: 4pcs AVR regulated plus surge protected | |||||||
| German or Universal: 2pcs AVR regulated plus surge protected | |||||||
| INDICATORS | |||||||
| LCD Display | Input voltage, Output voltage, Normal/Low Volt./Boost/Buck/High Volt./Overheat/Overload/Delay information | ||||||
| PROTECTION | |||||||
| Overload/Short Circuit | Manual reset circuit switch | ||||||
| Over Temperature | Thermal switch | ||||||
| Surge Protection | 330 Joules | ||||||
| ENVIRONMENT | |||||||
| Operating Temperature | 0°C-40°C (32°F-104°F) | ||||||
| Humidity | 0-95% (Non-condensing) | ||||||
| Noise Level | Less than 40dB at 1M | ||||||
| PHYSICAL | |||||||
| Dimension (D*W*H) | 270*95*190mm | ||||||
| Net Weight | 3.0kgs | 5.0kgs | 6.0kgs | ||||
| **Product specifications are subject to change without further notice. | |||||||
