PSC(U) Series 600VA-1000VA
AVR-Relay Type
PSC(U) Series600VA-1000VA
Power Star Color series AVR offers several colors for panels.It provides 1-step boost and 1-step buck to stable output voltage.
It provides built-in thermal switch for over-temperature protection to protect connecting loads.
Also, 5VDC 2.1A max USB charger is offered for smart phones and tablet charging.
PSC(U) Series 600VA-1000VA
- 5VDC USB charger 2.1A max. for charging iPad / iPhone / smartphone (Optional)
- Provide stable output voltage through boost and buck stabilizer
- Built-in thermal switch for over-temperature protection
- Provide modem / phone line surge protection
- Provide overload & short circuit protection
- Stylist design with colorful panels
- Anti-flammable plastic housing
| MODEL | PSC(U)-600 | PSC(U)-800 | PSC(U)-1000 | ||||
| CAPACITY | 600VA/300W | 800VA/400W | 1000VA/500W | ||||
| INPUT | |||||||
| Voltage | 110/115/120Vac or 220Vac | ||||||
| Voltage Range | 110/115/120Vac: 92-138Vac ; 220Vac: 184-276Vac | ||||||
| Frequency | 50/60Hz | ||||||
| OUTPUT | |||||||
| Steps of Regulation | 2-steps (1-step Boost & 1-step Buck) | ||||||
| Output Receptacles | Nema5-15R or Universal Nema: 4pcs AVR regulated & surge protected + 4pcs surge protected only | ||||||
| USB Charger (Optional) | PSC series: N/A | ||||||
| PSCU series: 2 ports 5VDC 2.1A Max. | |||||||
| Protection | Network surge suppression: RJ-45 (Optional for PSC series) | ||||||
| Overload/Short circuit: Manual reset circuit switch | |||||||
| Over-temperature: Thermal switch | |||||||
| INDICATORS | |||||||
| Power On/Off LED | Green | ||||||
| Regulation LED | Yellow | ||||||
| ENVIRONMENT | |||||||
| Humidity | 0-95% (Non-condensing) | ||||||
| Noise Level | Less than 40dB at 1M | ||||||
| PHYSICAL | |||||||
| Dimension (D*W*H) | 145*75.5*114mm | ||||||
| Net Weight | 1.0kg | 1.4kgs | 1.6kgs | ||||
| **Product specifications are subject to change without further notice. | |||||||
