AVR I-379U Series
600VA-800VA

AVR I-379U series offers 1-step boost and 1-step buck to stable output voltage. Built-in thermal switch can protect connecting loads from over-temperature. Equipped with 4 pcs 5VDC 2.4A max. USB power charger can charge smartphone, GPS, and tablet or other personal devices simultaneously. Stylist design and users-friendly housing for smartphone placement when charging.

AVR I-379U Series 600VA-800VA

  • 5VDC USB charging ports 2.4A max for iPhone, iPad, smartphones
  • Provide stable output voltage through boost and buck stabilizer
  • Built-in thermal switch for over-temperature protection
  • Slot for smartphone placement when charging
  • Provide overload & short circuit protection
  • 4 outlets protect peripherals and devices
  • User-friendly visual LED indicators
MODEL PS-379U-600 PS-379U-800
CAPACITY 600VA/300W 800VA/400W
INPUT
Voltage 110/115/120Vac or 220/230/240Vac
Frequency 50/60Hz
OUTPUT
Steps of Regulation 2-steps (1-step Boost & 1-step Buck)
Output Receptacles Nema5-15R or Universal Nema: 4pcs AVR regulated plus surge protected
5VDC USB Charging 4 ports 2.4A Max.
Protection Overload/Short circuit: Manual reset circuit switch
Over-temperature: Thermal switch
Surge protection: 175 joules
INDICATORS
Power On/Off LED Blue
Regulation LED Yellow
ENVIRONMENT
Humidity 0-95% (Non-condensing)
Noise Level Less than 40dB at 1M
PHYSICAL
Dimension 133*95*75mm
**Product specifications are subject to change without further notice.

AVR I-379U Series 600VA-800VA
