PSE Universal Series 800VA-2000VA
AVR-Relay Type
PSE Series 800VA-2000VAUniversal Socket
Power Star series(Universal) provides 3-steps voltage regulation to stabilize output voltage for protecting connected devices from damage.
To ensure safety of devices connection, Power star series embedded with thermal switch for over-temperature protection.
It also offers child protector socket design to avoid electric shock danger.
PSE Series 800VA-2000VA(Universal)
- Provide stable output voltage through boost and buck stabilizer
- Built-in thermal switch for over-temperature protection
- Provide modem / phone line surge protection
- Provide overload & short circuit protection
- Coaxial cable line protection (Optional)
- 5VDC USB charging port (Optional)
- User-friendly visual LED indicators
- Anti-flammable plastic housing
- Accept wide input range
- Wall mounting holes
- Cable collector
- Child protector
| MODEL | PSE-800R4 | PSE-1200R4 | PSE-2000R4 | ||||
| CAPACITY | 800VA/400W | 1200VA/600W | 2000VA/1000W | ||||
| INPUT | |||||||
| Voltage | 220/230/240Vac | ||||||
| Voltage Range | 161-288Vac | ||||||
| Frequency | 50/60Hz | ||||||
| OUTPUT | |||||||
| Steps of Regulation | 3-steps (2-steps Boost & 1-step Buck) | ||||||
| Output Receptacles | Universal: 3pcs AVR regulated & surge protected + 3pcs surge protected only | ||||||
| Protection | Network surge suppression: RJ-45 | ||||||
| Overload/Short circuit: Manual reset circuit switch | |||||||
| Over-temperature: Thermal switch | |||||||
| INDICATORS | |||||||
| Power On/Off LED | Green | ||||||
| Boost LED | Yellow | ||||||
| Buck LED | Yellow | ||||||
| ENVIRONMENT | |||||||
| Humidity | 0-95% (Non-condensing) | ||||||
| Noise Level | Less than 40dB at 1M | ||||||
| PHYSICAL | |||||||
| Dimension | 263*120*85mm | ||||||
| Net Weight | 1.6kgs | 2.0kgs | 2.3kgs | ||||
| **Product specifications are subject to change without further notice. | |||||||
