PS Nema5-15R Series 800VA-2000VA
AVR-Relay Type
PS Series 800VA-2000VAUS Socket
Power Star series(Nema5-15R) provides 3-steps voltage regulation to stabilize output voltage for protecting connected devices from damage.
To ensure safety of devices connection, Power Star series embedded with thermal switch for over-temperature protection.
Power Star Series 800VA-2000VA(Nema5-15R)
- Provide stable output voltage through boost and buck stabilizer
- Built-in thermal switch for over-temperature protection
- Provide modem / phone line surge protection
- Provide overload & short circuit protection
- User-friendly visual LED indicators
- Anti-flammable plastic housing
- Accept wide input range
| MODEL | PS-800 | PS-1200 | PS-2000 | ||||
| CAPACITY | 800VA/400W | 1200VA/600W | 2000VA/1000W | ||||
| INPUT | |||||||
| Voltage | 110/115/120Vac or 220/230/240Vac | ||||||
| Voltage Range | 110/115/120Vac: 90-144Vac ; 220/230/240Vac: 161-288Vac | ||||||
| Frequency | 50/60Hz | ||||||
| OUTPUT | |||||||
| Steps of Regulation | 3-steps (2-steps Boost & 1-step Buck) | ||||||
| Output Receptacles | 8pcs Nema 5-15R Outlets | ||||||
| Protection | Surge protection: 175 Joules | ||||||
| Overload/Short circuit: Manual reset circuit switch | |||||||
| Over-temperature: Thermal switch | |||||||
| INDICATORS | |||||||
| Power On/Off LED | Green | ||||||
| Output Cut off LED | Yellow | ||||||
| ENVIRONMENT | |||||||
| Humidity | 0-95% (Non-condensing) | ||||||
| Noise Level | Less than 40dB at 1M | ||||||
| PHYSICAL | |||||||
| Dimension | 245*89*87mm | ||||||
| **Product specifications are subject to change without further notice. | |||||||
